| 型号NO |
标称口径 |
软管的尺寸 |
外径 |
常用压力 |
弯曲半径 |
最长长度 |
| A |
B |
内径mm |
外径mm
|
mm |
Kgf/cm2 |
Mpa |
mm |
m |
| F119-6 |
10 |
3/8 |
19 |
21 |
26.0 |
10 |
0.98 |
500 |
10 |
| F119-8 |
15 |
1/2 |
19 |
21 |
26.0 |
10 |
0.98 |
500
|
10 |
| F119-12 |
20 |
3/4 |
19 |
21 |
26.0 |
10 |
0.98 |
500
|
10 |
| F119-16 |
25 |
1 |
23 |
25 |
33.3 |
8 |
0.78 |
600 |
10 |
| F119-20 |
32 |
1 1/4 |
30 |
33 |
41.0 |
6 |
0.58 |
700 |
4 |
| F119-24 |
40 |
1 1/2 |
39 |
42 |
46.8 |
6 |
0.58 |
1,000 |
4 |
| F119-32 |
50 |
2 |
46 |
50 |
60.7 |
5 |
0.49 |
1,600 |
4 |
| F119-40 |
65 |
2 1/2 |
62 |
66 |
75.2 |
3 |
0.29 |
2,000 |
4 |
| F119-48 |
80 |
3 |
72 |
76 |
91.8 |
3 |
0.29 |
2,400 |
4 |
F119-64
|
100 |
4 |
102 |
106 |
119.0 |
3 |
0.29 |
3,000 |
4 |
|
