| 型号NO |
标称口径 |
软管的尺寸 |
外径 |
SP径 |
耐压力 |
弯曲半径 |
重量 |
最长长度 |
| 常用压力 |
破坏压力 |
| A |
B |
内径mm |
外径mm |
mm |
mm
|
Kgf/cm2 |
Mpa |
Kgf/cm2 |
Mpa |
mm |
Kg/m
|
m |
| F140-6 |
10 |
3/8 |
16 |
18 |
19.0 |
1.8 |
10 |
0.98 |
450 |
44.10 |
250 |
0.6 |
10 |
| F140-8 |
15 |
1/2 |
16 |
18 |
19.0 |
1.8 |
10 |
0.98 |
450 |
44.10 |
250 |
0.6 |
10 |
| F140-12 |
20 |
3/4 |
19 |
21 |
22.0 |
2.0 |
10 |
0.98 |
350 |
34.30 |
300 |
0.7 |
10 |
| F140-16 |
25 |
1 |
23 |
25 |
26.0 |
2.0 |
10 |
0.98 |
300 |
29.40 |
400 |
0.9 |
10 |
| F140-20 |
32 |
1 1/4 |
33 |
36 |
37.0 |
2.5 |
10 |
0.98 |
240 |
23.52 |
500 |
1.9 |
10 |
| F140-24 |
40 |
1 1/2 |
39 |
42 |
43.6 |
3.0 |
10 |
0.98 |
240 |
23.52 |
800 |
2.2 |
4 |
| F140-32 |
50 |
2 |
49 |
53 |
54.6 |
3.5 |
10 |
0.98 |
160 |
15.68 |
1,200 |
3.4 |
4 |
| F140-40 |
65 |
2 1/2 |
62 |
66 |
68.0 |
4.0 |
8 |
0.78 |
110 |
10.78 |
1,800 |
5.3 |
4 |
| F140-48 |
80 |
3 |
77 |
81 |
83.0 |
5.0 |
6 |
0.58 |
80 |
7.84 |
2,200 |
7.3 |
4 |
| F140-64 |
100 |
4 |
96 |
100 |
102.0 |
5.0 |
5 |
0.49 |
70 |
6.86 |
2,600 |
9.8 |
4 |
|
